Selected Anion Result
Total Cyanide
< 0.01 mg/L
Reported below the stated laboratory detection limit.
Independent Laboratory Analysis
Laboratory Analysis of SGH® Leach Residue
Explore the TCLP characterization of solid leach residues identified as SGH® and NaCN samples, analyzed using US EPA SW-846 Method 1311.
- SGH® Residue
- NaCN Residue
- Inorganic & Organic Analysis
Test Protocol
TCLP · US EPA SW-846 Method 1311
- Client PT Dimar Reka Industri
- Sample Type Solid Leach Residue
- Test Method TCLP — US EPA SW-846 Method 1311
- Order Date May 26, 2026
Understanding the TCLP Analysis
Why Leach Residue Characterization Matters
The Toxicity Characteristic Leaching Procedure, or TCLP, is a laboratory extraction method used to evaluate the potential mobility of selected constituents from solid materials under specified test conditions. Residue characterization supports environmental screening, process evaluation, waste-management planning, and responsible mining practices.
Characterization, not a universal field simulation
The method evaluates submitted material under a defined laboratory extraction protocol.
Laboratory Workflow
US EPA SW-846 Method 1311
From Solid Residue to Constituent Profile
- Step 01 Solid Residue
- Step 02 Sample Preparation
- Step 03 TCLP Extraction
- Step 04 Laboratory Measurement
- Step 05 Constituent Profile
Analysis Coverage
Five Groups of Reported Parameters
- Inorganic Parameters
- Anions
- Organic Compounds
- Pesticides
- Additional Parameters
Key SGH® Residue Findings
Selected Results from the SGH® Residue Sample
In the submitted SGH® solid leach residue sample, total cyanide was reported below the stated laboratory detection limit of 0.01 mg/L.
- Hg Mercury < 0.01 mg/L
- Pb Lead < 0.01 mg/L
- Cd Cadmium < 0.01 mg/L
- Cu Copper < 0.01 mg/L
- Ni Nickel < 0.01 mg/L
- Se Selenium < 0.01 mg/L
- Ag Silver < 0.01 mg/L
- As Arsenic 0.01 mg/L
- Ba Barium 0.09 mg/L
- B Boron 0.06 mg/L
- Zn Zinc 0.05 mg/L
Results shown relate to the submitted SGH® solid leach residue sample and are presented as reported laboratory values. They do not establish zero concentration, an overall toxicity classification, or environmental certification.
SGH® and NaCN Comparison
Comparative Residue Characterization
A side-by-side presentation of selected results reported for two separately identified solid leach residue samples. All values are shown in mg/L.
Selected Comparison
Unit · mg/L
Reported Results at a Glance
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Total Cyanide | < 0.01 | < 0.01 |
| Arsenic | 0.01 | < 0.01 |
| Barium | 0.09 | 0.15 |
| Boron | 0.06 | 0.07 |
| Zinc | 0.05 | 0.08 |
| Chloride | 0.60 | 0.64 |
| Fluoride | < 0.06 | 0.07 |
| Mercury | < 0.01 | < 0.01 |
| Lead | < 0.01 | < 0.01 |
| Cadmium | < 0.01 | < 0.01 |
Complete Parameter Groups
Explore the Full Reported Dataset
Open each category to compare the two submitted residue samples. The symbol “<” denotes a result below the stated detection limit.
Inorganic Parameters16 parameters
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Antimony | < 0.02 | < 0.02 |
| Arsenic | 0.01 | < 0.01 |
| Barium | 0.09 | 0.15 |
| Beryllium | < 0.01 | < 0.01 |
| Boron | 0.06 | 0.07 |
| Cadmium | < 0.01 | < 0.01 |
| Chromium Hexavalent | < 0.08 | < 0.08 |
| Copper | < 0.01 | < 0.01 |
| Lead | < 0.01 | < 0.01 |
| Mercury | < 0.01 | < 0.01 |
| Molybdenum | < 0.01 | < 0.01 |
| Nickel | < 0.01 | < 0.01 |
| Selenium | < 0.01 | < 0.01 |
| Silver | < 0.01 | < 0.01 |
| Tributyltin Oxide * | < 0.008 | < 0.008 |
| Zinc | 0.05 | 0.08 |
Anions6 parameters
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Chloride | 0.60 | 0.64 |
| Cyanide (total) * | < 0.01 | < 0.01 |
| Fluoride | < 0.06 | 0.07 |
| Iodide * | < 0.04 | < 0.04 |
| Nitrate | < 0.02 | < 0.02 |
| Nitrite | < 0.01 | < 0.01 |
Organic Compounds36 parameters
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Benzene | < 0.003 | < 0.003 |
| Benzo(a)pyrene * | < 0.00002 | < 0.00002 |
| Carbon Tetrachloride | < 0.0004 | < 0.0004 |
| Chlorobenzene | < 0.0002 | < 0.0002 |
| Chloroform | < 0.002 | < 0.002 |
| 2-Chlorophenol | < 0.0005 | < 0.0005 |
| Total Cresol | < 0.001 | < 0.001 |
| Di(2-ethylhexyl) phthalate | < 0.002 | < 0.002 |
| 1,2-Dichlorobenzene | < 0.0005 | < 0.0005 |
| 1,4-Dichlorobenzene | < 0.0003 | < 0.0003 |
| 1,2-Dichloroethane | < 0.0004 | < 0.0004 |
| 1,1-Dichloroethene | < 0.0004 | < 0.0004 |
| 1,2-Dichloroethene * | < 0.0006 | < 0.0006 |
| Dichloromethane | < 0.003 | < 0.003 |
| 2,4-Dichlorophenol | < 0.0007 | < 0.0007 |
| 2,4-Dinitrotoluene | < 0.0006 | < 0.0006 |
| Ethylbenzene | < 0.004 | < 0.004 |
| EDTA * | < 0.05 | < 0.05 |
| Formaldehyde * | < 0.03 | < 0.03 |
| Hexachlorobutadiene | < 0.0005 | < 0.0005 |
| Methyl Ethyl Ketone | < 0.3 | < 0.3 |
| Nitrobenzene | < 0.0004 | < 0.0004 |
| Phenol (total, non-halogenated) * | < 0.1 | < 0.1 |
| Styrene | < 0.004 | < 0.004 |
| 1,1,1,2-Tetrachloroethane * | < 0.0002 | < 0.0002 |
| 1,1,2,2-Tetrachloroethane * | < 0.0004 | < 0.0004 |
| Tetrachloroethene | < 0.0003 | < 0.0003 |
| Toluene | < 0.005 | < 0.005 |
| Trichlorobenzene (total) * | < 0.006 | < 0.006 |
| 1,1,1-Trichloroethane | < 0.0005 | < 0.0005 |
| 1,1,2-Trichloroethane | < 0.0003 | < 0.0003 |
| Trichloroethene | < 0.0004 | < 0.0004 |
| 2,4,5-Trichlorophenol | < 0.0005 | < 0.0005 |
| 2,4,6-Trichlorophenol | < 0.0004 | < 0.0004 |
| Vinyl Chloride | < 0.0004 | < 0.0004 |
| Xylene (total) | < 0.007 | < 0.007 |
Pesticides8 parameters
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Aldrine + Dieldrine | < 0.0005 | < 0.0005 |
| DDT + DDD + DDE | < 0.0005 | < 0.0005 |
| 2,4-D * | < 0.0007 | < 0.0007 |
| Chlordane | < 0.0006 | < 0.0006 |
| Heptachlor | < 0.0007 | < 0.0007 |
| Lindane * | < 0.0007 | < 0.0007 |
| Metoxychlor | < 0.001 | < 0.001 |
| Pentachlorophenol | < 0.0005 | < 0.0005 |
Additional Parameters6 parameters
| Parameter | SGH® Residue | NaCN Residue |
|---|---|---|
| Endrine | < 0.0006 | < 0.0006 |
| Hexachlorobenzene | < 0.0006 | < 0.0006 |
| Hexachloroethane | < 0.0005 | < 0.0005 |
| Pyridine | < 0.06 | < 0.06 |
| Toxaphene | < 0.0003 | < 0.0003 |
| 2,4,5-TP (Silvex) * | < 0.0006 | < 0.0006 |
Scope, Important Notes & CTA
Responsible Interpretation of Laboratory Data
Laboratory results are most useful when their sample identity, test scope, detection limits, and reporting conditions are understood together. The information below preserves the essential context stated in the report.
Report Identification
Test References
- SGH® sampleCBT380110006608052026-02
- NaCN sampleCBT380110006608052026-01
- Sample IDSolid Residue Leach SGH and Solid Residue Leach NaCN
- Client referenceMIN.IWO.26.03806-03807
Reporting Context
Important Notes from the Report
These conditions define how the published summary should be read and used.
Customer sampling. Sampling was carried out by the customer.
Sample-specific results. Results relate only to the samples submitted for analysis.
Process-dependent characteristics. Residue characteristics may change according to ore mineralogy, reagent dosage, pH, process duration, and other operating conditions.
Accreditation notation. Parameters marked with an asterisk were stated as outside the scope of KAN accreditation.
Total cyanide notation. Cyanide (total) is marked with an asterisk in the report.
No regulatory determination. The report does not provide a regulatory pass/fail conclusion.
Reproduction restriction. The report states that it may not be reproduced except in full context and with prior written approval from the laboratory.
Technical Documentation
Request the Complete Technical Documentation
Contact the EcoGold technical team to discuss the laboratory findings, ore-specific testing, processing configuration, and residue characterization requirements.
